The Problem Arises
A couple of weeks ago, we attempted to upgrade our Erlang/OTP version from 24 to 25.3.2.16, which was the latest release at the time. Unfortunately, shortly after the new release containing this change was deployed to production, our Customer Service team reported that a specific payment feature had stopped working. In fact, they noticed that we had stopped receiving this type of payment almost immediately after the new release hit production. The timing was too suspiciously close for this to be a coincidence.
The Investigation
When investigating this issue, I had no idea what the cause was, but I did have significant time pressure due to the nature of the problem—payments not being processed is always urgent!
First thing I did was to understand where the failure was happening and managed to replicate it in my local environment. Next, I methodically went through the all the changes in this release, reverting suspicious-looking changes one by one. Surprisingly, none of our actual code changes was the culprit.
The OTP version upgrade had seemed like one of the most innocent changes with regard to the payment issue we were facing. However, after exhausting other possibilities, I tested against OTP 24 since the OTP upgrade was a relatively major change in the same release. I was quite shocked to discover that the new version of OTP was indeed the guilty party.
The (Partial) Solution
Since I’m not an expert on certificate validation in Erlang, the error message we got when making requests to the bank looks cryptic:
TLS :client: In state :wait_cert_cr at ssl_handshake.erl:2123 generated CLIENT ALERT: Fatal - Unsupported Certificate
- {:key_usage_mismatch,
{ {:Extension, {2, 5, 29, 15}, true, [:keyCertSign, :cRLSign]},
{:Extension, {2, 5, 29, 37}, false,
[{1, 3, 6, 1, 5, 5, 7, 3, 2}, {1, 3, 6, 1, 5, 5, 7, 3, 1}]}}}
But armed with this error message, I was able to find a Github issue in the official OTP repository about the same problem. Apparently other developers making HTTP requests with Erlang/Elixir had encountered the same issue.
Thanks to Ingela Andin, the maintainer, and the community’s efforts, a fix had already been released for OTP 26 and 27. But unfortunately for us, there was an impression that OTP 25 wasn’t affected, so no fix had been done for it. Given our urgent situation, we decided to revert back to OTP 24 to restore payment processing as quickly as possible.
It’s worth noting that after I reported that OTP 25 was indeed affected by the same issue, Ingela responded quickly and worked on backporting the fix. A new patch version with the fix was released about two weeks ago, clearing our path to safely upgrading to OTP 25.
Now that we had a solution, I wanted to better understand what caused the problem in the first place.
Understanding Digital Certificates
To understand the bug, we need a quick primer on SSL/TLS certificates: digital certificates are like digital ID cards that websites use to prove their identity. Each certificate contains:
- The website’s public key
- Information about the website (domain name, etc.)
- Information about how the certificate can be used
- A signature from a trusted Certificate Authority (CA)
Certificates have “extensions” that specify what they can be used for. Two important ones are:
- Key Usage (KU): Broadly defines what the certificate’s key can do (sign things, encrypt things, etc.)
- Extended Key Usage (EKU): More specifically defines the certificate’s purpose (web server authentication, email, etc.)
The Bug in OTP
The bug occurred because recent versions of OTP was enforcing a rule that wasn’t actually specified in the certificate standards (RFC 5280).
In simple terms:
- The certificates from certain CAs like Entrust had a flag set indicating they could sign other certificates (keyCertSign)
- They also had flags set saying they could be used for web server authentication
- OTP thought these two purposes were contradictory and rejected the certificate
It’s like if you’re qualified as both a teacher and a restaurant chef, but then a bureaucrat refused to accept because “you can’t possibly do both these unrelated jobs.” In reality, of course, there’s no reason someone couldn’t be qualified for both roles independently.
And same goes for digital certificates. The certificate standard (RFC 5280) allows certificates to serve multiple purposes simultaneously, but OTP’s new validation logic was too restrictive.
For those interested in further technical details, there are extensive discussions in the Github issue and here is the PR that fixed it.
Takeaways
A few interesting lessons from this experience:
- Hidden Complexity: Even mature, well-tested software like Erlang/OTP can have subtle bugs in complex areas like SSL/TLS.
- Implementation vs. Specification: The bug wasn’t a coding error but an overly strict interpretation of a technical standard.
- Community Matters: Thanks to the Erlang community for identifying and fixing this issue very quickly.
Summary
In this post, we started with an unexpected payment issue in production from upgrading the OTP version to 25. After identifying the new OTP version as the culprit, we had to revert back to OTP 24.
We also dove into understanding how the bug happened, which was essentially an overly strict interpretation of certificate standards. Thanks to the responsive Erlang community and OTP maintainers, a fix was backported to OTP 25, resolving the bug.
For me this was quite an interesting experience, because the overwhelming majority of bugs we face as developers are introduced by ourselves in the application layer. Sometimes we do encounter bugs in the library or framework that we use, but that’s pretty rare. It is ultra rare to face a bug in the underlying programming language. In fact, this was the very first one I had in my whole career as a developer, and I’ve been doing this for almost 20 years.
